The Braeburn 1020NC gives you simple, non-programmable temperature control for standard single-stage systems in a compact, builder-friendly package. It keeps the basics covered: clear backlit display, dual power options, and protection features, without adding extra menus or complexity for the homeowner.
Key Features & Benefits
Non-Programmable Single-Stage Control
Digital non-programmable thermostat for 1 heat / 1 cool conventional or heat pump systems, and compatible with many 250–750 mV millivolt heating appliances.
Compact Backlit Display
Large 2 sq. in. horizontal LCD with bright blue backlight provides clear temperature and status information in a smaller footprint than the standard 1020.
Dual Power Options
Can be powered by 24 VAC or by two AA alkaline batteries, giving flexibility for new installs and retrofits while retaining settings during power loss.
Adjustable Limits And Differential
Adjustable temperature limits and adjustable temperature differential help control extreme setpoints and fine-tune cycle length to match the system and space.
Compressor Short Cycle Protection
Built-in short cycle protection helps prevent rapid compressor cycling to reduce wear on cooling equipment.
Separate O And B Terminals
Separate O and B terminals support single-stage heat pump applications with either cool-active or heat-active reversing valves.
ESD Guard And Reset Button
ESD Guard™ electronic circuitry and a front access reset button add protection and give a quick way to restore factory defaults during service.
Fahrenheit/Celsius And Fan Switches
Includes °F/°C selection and a gas/electric fan switch so you can match display units and fan control to the equipment and user preference.
Optional Wall Plate And Branding
Works with optional wall plate 2950 and offers contractor branding options on packaging and cards for builder or light commercial projects.
Key Specs
Application: Non-programmable single-stage wall thermostat, 1 heat / 1 cool
System Compatibility: Single-stage gas, oil, electric or hydronic; single-stage heat pump; 250–750 mV millivolt heating systems
Stages: 1 Heat / 1 Cool
Display Size: 2 sq. in. bright blue backlit LCD
Programming: Non-programmable (manual setpoint)
Power Options: 24 VAC (18–30 VAC) and/or 3.0 VDC from two AA alkaline batteries
Electrical Rating: 24 VAC; 1 A max load per terminal; 3 A total max load (all terminals)
Control Range: 45–90°F (7–32°C)
Display Range: 40–99°F (5–37°C)
Temperature Accuracy: ±1°F (±0.5°C)
Temperature Differential: Selectable 0.5°, 1°, or 2°F (0.2°, 0.5°, or 1°C)
Backlight: Bright blue backlight (Yes)
Changeover: Manual
Terminals: Rc, Rh, O, B, Y1, W1, G, C
Voltage: 24 VAC control
Operating Humidity: 5–95% RH, non-condensing
Dimensions: 3.62″ × 4.72″ × 1.38″
