The PRO1 IAQ T701 is a dependable, no-nonsense solution for single-stage HVAC applications where simplicity and reliability matter most. Designed for 1 heat / 1 cool conventional or heat pump systems, this non-programmable thermostat is ideal for rental properties, vacation homes, small offices, and any space where straightforward temperature control is preferred over complex scheduling or smart-home features.
Built with professional-grade protection in mind, the T701 features a selectable 5-minute compressor delay that guards equipment against short-cycling damage — a critical safeguard that extends system life and reduces service calls. Customizable staging logic and independent heating and cooling swing adjustments (0.2°F to 2.0°F) give installers the precision needed to optimize comfort and efficiency for each unique application.
Dual power options — hardwire (18–30 VAC, NEC Class II) or 2 AA alkaline batteries — provide installation flexibility regardless of wiring configuration. A large 4 sq. in. display with blue backlight and glow-in-the-dark light button ensures easy readability in any lighting condition. Setpoint limits prevent unauthorized temperature changes in rental or commercial environments, while the universal subbase and tool-free battery compartment make installation and maintenance fast and hassle-free.
The T701 also features a simple private label badge system, making it an attractive option for contractors who want to present a branded thermostat to their customers. Backed by a 5-year limited warranty, the T701 delivers professional performance and lasting value at an accessible price point.
Features
- Application: 1 stage of heat / 1 stage of cool – conventional or heat pump
- Programmability: Non-programmable (manual setpoint control)
- Dual power options: Hardwire (18–30 VAC, NEC Class II, 50/60 Hz) or 2 AA alkaline batteries
- Selectable 5-minute compressor delay protection (on/off) guards against short-cycling damage
- Customizable staging logic for optimized system response
- Separate heat & cool swing adjustments: 0.2°F to 2.0°F for precise cycle rate control
- 4 sq. in. display with blue backlight for easy readability
- Glow-in-the-dark light button for visibility in any lighting condition
- Setpoint limits prevent unauthorized temperature adjustments
- Universal subbase for fast, straightforward installation
- Tool-free easy-access battery compartment
- Simple private label badge system for contractor branding
Specifications
- Display range: 41°F to 95°F (5°C to 35°C)
- Control range: 44°F to 90°F (7°C to 32°C)
- Display accuracy: ±1°F
- Terminals: Rc, Rh, G, Y, W, C, O, B
- Load rating: 1 amp per terminal, 1.5 amp maximum combined
- Operating ambient: 32°F to 105°F (0°C to 41°C)
- Operating humidity: 90% non-condensing maximum
- Mounting: Wall or junction box
- Dimensions: 4.7″W x 4.4″H x 0.8″D (119mm W x 112mm H x 20mm D)
- Warranty: 5-year limited warranty
Typical Applications
Single-family homes, rental properties, vacation homes, apartments, small offices, retail spaces, and any single-stage HVAC system where simple, reliable temperature control is needed without programming complexity.
