Raymarine Low Profile Bronze Depth Only [E66014]

Low Profile Bronze Depth Only
Depth only low profile transducer (B117)

Compatible with the following Echo Sounders:

• DSM250 and DSM300
• SL Series: SL755RC, SL760RC , SL1250, and SL1250RC
• hsb2 Plus Series: L755RC, L760, L760RC, L1250,and L1250RC
• hsb2 HDFI Series: DSM250, L770D, L770DRC, L1260D, and L1260DRC

Compatible hull material: wood and fiberglass

Max Power: 600 W

Frequency: 200/50 kHz

Cable: 30ft (10m) cable with connector

**Requires E66066 adapter cable to work with a,c,e,eS Series built in sonar models.**

Specifications:

• Mounting Style: Thru-Hull
• Imaging: Standard
• Chirp: No
• Cable Length (Feet): 30′
• Temperature: No
• Speed Included: No
• Box Dimensions: 4″H x 7″W x 10″L WT: 3.9 lbs
• UPC: 023193660141

Owner’s Manual (pdf)
Brochure (pdf)
