FEATURES
- 60% larger LCD display with backlight.
- Permanent program retention during power loss.
- Configuration menu allows keypad selection of options.
- Selectable Celsius or Fahrenheit temperature display.
- Selectable Energy Management Recovery.
- Classic White color.
SPECIFICATIONS
- Electrical Rating; 20 to 30 VAC, NEC Class II
- Terminal Load: 1.0 A per terminal, 1.5 A maximum all terminals combined
- Setpoint Range: 45 to 90°F (7 to 32°C)
- Rated Differential (Multi-Stage): Heat 0.6° or 1.5°F Cool 1.2°F
- Rated Differential (Heat Pump): Heat & Cool 0.75° or 1.2°F
- Operating Ambient:32 to +105°F (0 to +41°C)
- Operating Humidity: 90% non-condensing max.
- Shipping Temperature Range: -4 to 149°F (-20 to 65°C)
- Dimensions: 6″H x 33/4″W x 11/4″D
